Suzuki Workshop Service and Repair Manuals > XL-7 Plus 4WD V6-2.7L (2002) > Powertrain Management | Sensors and Switches - Powertrain Management | Sensors and Switches - Computers and Control Systems | Power Steering Pressure Switch | Component Information | Locations

Power Steering Pressure Switch|Locations|Page 1397 > < Heated Oxygen Sensor (Sensor 1)|Page 1393

Page 1

background image

Engine Room Part 2

Powertrain Management
Sensors and Switches - Powertrain Management / Sensors and Switches - Computers and Control Systems
Power Steering Pressure Switch
Component Information
Locations

Power Steering Pressure Switch|Locations|Page 1397 > < Heated Oxygen Sensor (Sensor 1)|Page 1393
