Golf GL L4-2.0L (AZG) (2001)
/Page-3003.png)
-
The -> button is used for advancing through the program sequence.
-
The PRINT button is used for switching on the printer (lamp in button lights up).
Indicated on display (* is displayed alternately):
VAG - On Board Diagnostic
HELP
1 - Rapid data transfer*
2 - Blink code output*
-
Press button 1 for "Rapid data transfer".
-
Continue On Board Diagnostic (OBD) of vehicle system to be tested as described under "performing On Board Diagnostic (OBD).
Connecting VAG 1551
Special tools and equipment
-
VAG 1551 Scan Tool (ST)
-
VAG 1551/3B cable
-
VAS 5051 Vehicle Diagnostic Testing and Information System
VAS 5051 Or VAG 1551, Connecting
