Jetta L4-1.9L DSL Turbo (BEW) (2004)
-
3409 Wedge
-
Piston resetting tool
Removing
-
Force piston out of brake caliper housing using compressed air.
Note: Place a piece of wood in the recess to prevent damaging the piston.
-
Remove seal using wedge 3409.
Note: When removing ensure that the surface of the cylinder is not damaged.
Installing
-
The surface of the piston and seal must only be cleaned with methylated spirits and then dried.
-
Thinly coat piston and seal with paste G 052 150 A2 before inserting.
-
Insert oil seal in brake caliper housing.
