Jetta L4-1.9L DSL Turbo (BEW) (2004)
/Page-511001.png)
Front Crankshaft Seal: Service and Repair
Crankshaft oil seal - belt pulley end, replacing
Special tools, testers and auxiliary items required
^
Counterhold 3099
^
Oil seal extractor 3203
^
Assembly tool T1 0053
^
Torque wrench (5 ... 50 Nm) V.A.G. 1331
^
Torque wrench (40 ... 200 Nm) V.A.G. 1332
Removing
-
Remove toothed belt.
-
Remove crankshaft toothed belt pulley by counterholding toothed belt pulley with counterhold 3099
Note: When bolting on the counterhold place two washers between the toothed belt pulley and the counterhold.
