Jetta L4-1781cc 1.8L SOHC (ACC) Can (1995)

Engine, Cooling and Exhaust > Cooling System > Lamps and Indicators - Cooling System > Temperature Gauge > Component Information > Diagrams > Page 1731

Page 1
background image

Temperature Gauge: Testing and Inspection

Tools required:

-

Instrument tester VW 1301

-

Connector test kit V.A.G 1594/A

-

Test box V.A.G 1598 with adapter V.A.G 1598/8

-

Digital multimeter Fluke 83 (US 1119)
