Jetta L5-2.5L (CBTA) (2008)

Page 11
background image

44 - Ground Connection, On Left A-pillar, Lower Part, 602 - Ground Point In Floor Outlet Front, Left

45 - Ground Connection, Behind Instrument Panel, Center

605 - Ground Connection (On Upper Steering Column)
