Jetta SportWagen (AJ5) L4-2.0L DSL Turbo (CJAA) (2011)
/l4-2.0l_dsl_turbo_(cjaa)/Page-106001.png)
Cabin Air Filter: Service and Repair
Dust And Pollen Filter, Removing And Installing
Removing:
-
Remove front passenger footwell trim -1-.
-
Remove partition -2-
-
Release cover -3- in direction of -arrows-.
-
Pull dust and pollen filter downward from heating and ventilation unit.
NOTE: Observe installation orientation of dust and pollen filter.
Installing:
Install in reverse order of removal, noting the following.
-
Insert filter element into heating and ventilation unit in direction of -arrow-.
