Impact Sensor: Locations
Crash Sensor For Driver-Side and Passenger Side - Side Airbag, Assembly Overview

Crash Sensor For Driver-side And Passenger Side - Side Airbag, Assembly Overview

1. Driver-side and passenger-side sensor
2. Connector
3. Bolt

-

Qty. 2, 6 Nm

4. Carpet
