New Beetle L5-2.5L (BPR) (2007)
-
Rotate the belt tensioner - 2 - using a 15 mm box end wrench - A - in the - direction of the arrow - and secure using (T10060A).
-
Remove the ribbed belt for the generator, power steering and coolant pumps.
Installing
Installation is performed in reverse order. When doing this note the following:
-
Place the ribbed belt for the generator, power steering and coolant pumps onto the pulleys, then lastly onto the idler pulley - 3 -.
-
Before tensioning the ribbed belt for the generator, power steering and coolant pumps, rotate the A/C compressor belt tensioner and check the belt
for correct seating in the pulley.
-
Before installing the ribbed belt for the A/C compressor, secure the tensioner using (T10060A).
‹› When installing the belt, note the direction of rotation of the belt and be sure that it is seated correctly on the pulley.
-
Start the engine and check the belt running.
