Passat 4Motion V6-2.8L (ATQ) (2005)
/Page-1878001.png)
Fluid Filter - A/T: Service and Repair
ATF strainer, removing and installing, 01V, 5 SPD. A/T (AWD)
Removing
^
Remove oil pan.
^
Remove bolts - arrows - for oil strainer.
^
Pull off oil strainer from valve body.
Installing
^
Coat seal on strainer suction collar with ATF.
^
Carefully press suction collar into the opening at valve body up to stop.
^
Tighten bolts.
^
Install oil pan.
^
Add ATF, check ATF level and top off.
