Passat Wagon L4-2.0L Turbo (BPY) (2008)
If no malfunctions are found in the wiring:
Checking Ground (GND)
If the manufacturers test box is being used. Perform the following step.
-
Install the test box.
If the manufacturers test box is not being used. Perform the following step.
-
Remove the Motronic Engine Control Module (ECM) (J623). Refer to => [ Motronic Engine Control Module J623, Replacing ] See: Relays and
Modules - Computers and Control Systems/Engine Control Module/Service and Repair/Motronic Engine Control Module J623, Replacing.
-
Using a Multimeter, check the following wiring connection for resistance.
Specified value: 1.5 ohms.
If the specified value was not obtained:
-
Check the Motronic Engine Control Module (ECM) Power Supply Relay (J271) socket 4/85 to the Motronic Engine Control Module (ECM)
(J623) electrical harness connector T94 terminal 69 for an open circuit or a short to Battery (+).
-
Check the electrical harness connector for damage, corrosion, loose or broken terminals.
-
If necessary, repair the wiring connection.
If no malfunctions are found in the wiring and the voltage supply was OK:
-
Replace the Motronic Engine Control Module (ECM) Power Supply Relay (J271).
-
Perform a road test to verify repair.
If the fault does not return:
Repair complete, Generate readiness code. Refer to => [ Readiness Code ] See: Powertrain Management/Computers and Control Systems/Testing and
Inspection/Monitors, Trips, Drive Cycles and Readiness Codes/Readiness Code.
-
End diagnosis.
If the fault does return and no malfunction is detected in the wiring and the voltage supply was OK:
-
Replace the Motronic Engine Control Module (ECM) (J623). Refer to => [ Motronic Engine Control Module J623, Replacing ] See: Relays and
Modules - Computers and Control Systems/Engine Control Module/Service and Repair/Motronic Engine Control Module J623, Replacing.
-
Assembly is performed in the reverse of the removal.
Final Procedures
After the repair work, the following work steps must be performed in the following sequence:
1. Check the DTC memory. Refer to => [ Diagnostic Mode 03 - Read DTC Memory ] See: Powertrain Management/Computers and Control
Systems/Testing and Inspection/Scan Tool Testing and Procedures/Diagnostic Modes 01 - 09/Diagnostic Mode 03 - Read DTC Memory.
2. If necessary, erase the DTC memory. Refer to => [ Diagnostic Mode 04 - Erase DTC Memory ] See: Powertrain Management/Computers and
Control Systems/Testing and Inspection/Scan Tool Testing and Procedures/Diagnostic Modes 01 - 09/Diagnostic Mode 04 - Erase DTC Memory.
3. If the DTC memory was erased, generate readiness code. Refer to => [ Readiness Code ] See: Powertrain Management/Computers and Control
Systems/Testing and Inspection/Monitors, Trips, Drive Cycles and Readiness Codes/Readiness Code.
End of diagnosis.
