Polo Mk3

General body repairs, exterior
Front bumper 10.99 >
Bumper carrier - Assembly overview

N63-0068
  • Bumper carrier
  • Bolt
    • ◆ Qty. 4
    • ◆ 23 Nm
  • Bolt
    • ◆ Qty. 3
    • ◆ 14 Nm
  • Spreader nut
    • ◆ Qty. 4
  • Guide
    • ◆ To remove/install bumper, pull out or push in parallel to guides at left and right.
  • Bolt
    • ◆ Qty. 2
    • ◆ 2 Nm
  • Bolt
    • ◆ Qty. 4
    • ◆ 1.5 Nm
