Polo Mk3
| Assembly overview - handbrake lever |
| 1 - | Handbrake lever |
| 2 - | Handle |
| q | Press down locking lug underneath handle using a small screwdriver and pull off forwards |
| 3 - | Handbrake cover |
| q | Pull off upwards |
| 4 - | Hexagon nut, 25 Nm |
| 5 - | Compensator |
| 6 - | Handbrake cable |
| q | Removing and installing (drum brakes) → Chapter |
| q | Removing and installing (disc brakes) → Chapter |
| 7 - | Adjusting nut |
| q | Adjusting handbrake: |
| q | Vehicles with drum brakes → Chapter |
| q | Vehicles with disc brakes → Chapter |
| 8 - | Hexagon nut |
| q | Lock using adjusting nut |
|
|
