| Release the Claws -T10064/6A- from the wheel hub with wheel bearing |
| 1 - | Wheel hub with wheel roller bearing |
| –
| Install the drive shaft on the wheel roller bearing case. |
Note | Check if the bellows are not damaged or twisted. |
WARNING | Replace self-locking nuts and screws subject to angular torque |
|
| –
| Install the fastening screws (screws on the old markings)
for the wishbone swivel guide. Tightening torque, see → Anchor. |
| –
| Install the steering terminal in the wheel roller bearing
case. Tightening torque, see → Anchor. |
| –
| Install the coupling rod. Tightening torque, see → Anchor. |
| –
| Install the front wheel and tighten the screws. Tightening
torque, see → Chapter. |
| –
| Install and tighten the grooved nut (dodecagonal). Tightening
torque, see → Chapter. |
|
|
|
