Volkswagen Workshop Service and Repair Manuals > R32 4Motion V6-3.2L (CBRA) (2008) > Power and Ground Distribution | Fuse | Component Information | Application and ID | Fuses In Engine Compartment | Page 4130

Fuses In Engine Compartment|Page 4131 > < Fuses In Engine Compartment|Page 4129

Page 7

background image

Fuse Colours

Fuse Arrangements Electronics Box Low Part 1

Power and Ground Distribution
Fuse / Component Information
Application and ID / Fuses In Engine Compartment
Page 4130

Fuses In Engine Compartment|Page 4131 > < Fuses In Engine Compartment|Page 4129
