Filling gearbox oil
Filling gearbox oil
Filling gearbox oil
l
The oil drain plug is tightened to 30 Nm.
Gearbox oil
→ Electronic parts catalogue (ETKA)
Top up gearbox oil in container to 1.1 l.
The gearbox oil is filled through the sealing plug hole
-arrow-
.
It is accessible from beneath vehicle.
–
Remove sealing plug
-arrow-
.
Note
The area beneath the sealing plug
-arrow-
must be covered with a cloth.
–
Connect a hose
-A-
to a commercially available funnel and route hose through engine compartment past engine cover and air filter.
t
Hose length = approx. 600 mm
t
Outer diameter = max. 22 mm
–
Fit hose
-A-
into sealing plug hole and fill gearbox oil.
–
Install sealing plug and tighten securing bolt to 5 Nm + turn 90° further
-Pfeil -
.
l
If oil should get on gearbox and other components, remove it thoroughly.
