Cut the required length (+10 mm) of fiber optic.
Strip the fiber optic. Use: 951 2868 Fiber cutter See: Tools and Equipment/951 2868 Fiber Cutter  as illustrated

Cut the fiber optic. Use: 951 2868 Fiber cutter See: Tools and Equipment/951 2868 Fiber Cutter  as illustrated.

Relays and Modules > Relays and Modules - HVAC > Control Module HVAC > Component Information > Diagrams > Diagram Information and Instructions > Page 1020
