A3 Mk1
Vehicle electrics
Radio, telephone and navigation system / Infotainment / Radio system
Removing and installing bass loudspeaker
Removing and installing bass loudspeaker
Removing and installing bass loudspeaker
Note!
If fitted, CD changer must be removed
→ Chapter
.
–
Switch off all electrical equipment.
–
Remove ignition key.
Removing:
–
Remove left luggage compartment side trim
→ General body repairs, Interior; Rep. Gr.70
.
–
Unfasten nuts
-2-
(3 Nm).
–
Unplug connector at bass loudspeaker
-1-
.
–
Take out bass loudspeaker
-1-
.
Installing:
–
Install accordingly in reverse order of removal.
Vehicle electrics
Radio, telephone and navigation system / Infotainment / Radio system
Removing and installing bass loudspeaker
