A6 Quattro Sedan V8-4.2L (BVJ) (2007)
2. Intake camshaft
‹› Groove on end of shaft must lie as shown in illustration.
Continued for both sides:
-
Check location of compression ring ends.
‹› The compression ring ends - 1 and 2 - must face upward or downward, and must never face sideways.
-
Cut off nozzle on tube of sealant at front mark (dia. of nozzle approx. 2 mm).
-
Lay seal - 2 - in guide frame groove.
