A6 Quattro Sedan V8-4.2L (BVJ) (2007)
/Page-2120003.png)
CAUTION!
Risk of injury when touching "TDC" hole with finger.
‹› Do not rotate crankshaft - 1 -.
-
Install crankshaft holder (3242) into hole to 20 Nm, if necessary rotate crankshaft very slightly back and forth to completely center holder.
-
Press left camshaft timing chain tensioner glide track inward with a screwdriver - 1 - as far as stop and secure chain tensioner with Locking Pin
(T40071).
‹› The toothed belt tensioner is lubricated with oil and should only be compressed slowly by applying constant pressure.
