7 Series E38 740iL (M62) SAL
Turn engine on central screw counter-enginewise up to 45
°
before
TDC position.
Note markings!
Loosen grub screw.
Note:
Grub screw secures the angle bracket (1) in the cylinder head.
Unfasten guide rail and retaining screw for oil separator.
Lift oil separator out of angle bracket.
Caution!
When lifting the cylinder head, press oil separator outwards.
RA Removing and installing left cylinder head (M62 up to 9/98)
