X Series E53 X5 3.0d (M57) OFFRD
11 28 050
Replacing A/C compressor drive belt (M57 /
M47TU)
Remove front splash guard.
Press belt tensioner back at hexagon head (1).
Remove drive belt (2).
Installation:
Check drive belt for coolant and oil residue and replace if
necessary.
Caution!
The drive belt must be replaced if it is contaminated with
hydraulic fluid.
Fit drive belt and check if it is correctly located on pulleys.
RA Replacing A/C compressor drive belt (M57 / M47TU)
