DeVille DTS V8-4.6L VIN 9 (2002)
Cowl Moulding / Trim: Service and Repair
Air Inlet Grille Panel Replacement
Removal Procedure
Notice: Be sure to follow the service procedure when removing the air inlet grille panel. Failure to follow service procedure may cause damage to
the air inlet grille panel or the windshield.
1. Open the hood.
2. Remove the windshield wiper arms. Refer to Wiper Arm Replacement .
3. Remove the hood seal, rear. Refer to Seal Replacement - Hood Rear (See: Doors, Hood and Trunk/Hood/Hood Weatherstrip/Service and
Repair/Seal Replacement - Hood Rear) .
4. Remove the push in retainers (2) securing the air inlet grill panels (1) to the vehicle.
5. Disconnect the washer hose connector.
6. Push the washer hose grommet into the plenum area.
7. Remove the air inlet grille panel from the vehicle.
Installation Procedure
1. Position the washer hose and the washer hose grommet through the hole in the plenum area.
2. Press the washer hose grommet into position and ensure that it is fully seated.
3. Install the air inlet grille panels (1) to the vehicle.
4. Connect the washer hose connector.
5. Install the push in retainers (2) in order to secure the air inlet grille panel (1) to the body.
6. Install the windshield wiper arms. Refer to Wiper Arm Replacement in Wipers/Washer Systems.
7. Close the hood.
