XLR V8-4.6L VIN A (2006)
23. Connect the battery ground cable.
Caution: Refer to Restraint System Service Precautions in Service Precautions.
24. Enable the SIR system. Refer to the following procedures in Restraint Systems.
*
SIR Disabling and Enabling Zone 3
*
SIR Disabling and Enabling Zone 4
*
SIR Disabling and Enabling Zone 5
Instrument Panel (I/P) Trim Panel Replacement - Left
Instrument Panel (I/P) Trim Panel Replacement - Left
Removal Procedure
1. Remove the knee bolster trim panel.
2. Remove the retaining screw at the bottom of the trim panel.
3. Pull the left trim panel outward to disengage the retaining clips from the I/P carrier.
4. Disconnect the electrical connectors.
