13. Install the engine support fixture J-28467-B. Support the engine.

14. Remove the engine bracket-to-mount bolts.

15. Raise the engine using the engine support fixture J-28467-B.
16. Remove the power steering pump pulley bolts. Remove the power steering pump pulley.
