S15/T15 Jimmy 2WD L4-119 1.9L VIN A 2-BBL (1983)
Fig. 7 Measuring Brake Drum Inside Diameter
Fig. 8 Adjusting Brake Shoes To Brake Drum Inside Diameter
10.
Using suitable brake drum to shoe gauge, Fig. 5, measure brake drum inside diameter. Adjust brake shoes to dimension obtained on outside
portion of gauge, Fig. 6.
11.
Install brake drum, tire and wheel assembly.
12.
If any hydraulic connections have been opened, bleed brake system.
13.
Adjust parking brake. Refer to individual truck chapters for procedures.
14.
Inspect all hydraulic lines and connections for leakage, and repair as necessary.
15.
Check master cylinder fluid level, and replenish as necessary.
16.
Check brake pedal for proper feel and return.
17.
Lower vehicle and road test.
CAUTION: Do not severely apply brakes immediately after installation of new brake linings or permanent damage may occur to linings, and/or
brake drums may become scored. Brakes must be used moderately during first several hundred miles of operation to ensure proper burnishing of
linings.
