Pilot 4WD V6-3.5L (2008)
2. Connect the shift lock solenoid connector (C) and park pin switch connector (D).
3. Push the shift cable (A) until it stops, then release it. Pull the shift cable back two steps so that the shift position is in N. Do not hold the shift cable
guide (B) and damper (C) to adjust the shift position.
4. Turn the ignition switch ON (II), and check that the N position indicator comes on.
5. Turn the ignition switch OFF.
6. Place the shift lever in the N position, then insert a 6.0 mm (0.24 in.) pin (A) through the positioning hole (B) on the detent plate, and into the
positioning hole (C) on the control bracket. The shift lever is secured in the N position.
