Sonata V6-3.3L (2006)
COMPONENTS
REMOVAL
1. Loosen the wheel nuts slightly. Raise the front of the vehicle, and make sure it is securely supported.
2. Remove the front wheel and tire from front hub.
CAUTION: Be careful not to damage the hub bolts when removing the front wheel and tire.
3. Remove the upper arm ball joint self-locking nut (A) and the split pin (B).
