Discovery II
EXTERIOR FITTINGS
76-2-8
REPAIRS
Roof bars
$% 76.11.31
Remove
1. Remove headlining.
2. Models with rear A/C: Drill out 4 rivets
securing rear centre duct to roof.
3. Models with rear A/C: Release and remove
rear centre duct.
4. Models with rear A/C: Drill out 2 rivets
securing each upper side duct to roof.
5. Models with rear A/C: Remove upper side
ducts.
6. Remove 2 nuts securing each roof bar to roof.
7. Remove roof bars and collect foam pads from
each end.
Refit
1. Fit roof bars to roof, ensuring foam pads are
correctly located.
2. Fit nuts securing roof bars to roof and tighten
to 32 Nm (24 lbf.ft).
3. Models with rear A/C: Fit upper side ducts and
secure with rivets.
4. Models with rear A/C: Fit rear centre duct and
secure with rivets.
5. Fit headlining.
