Discovery II
IN CAR ENTERTAINMENT
DESCRIPTION AND OPERATION
86-6-1
IN CAR ENTERTAINMENT
DESCRIPTION AND OPERATION
ICE System Component layout
High line RHD system shown (LHD system similar)
1 FM aerial and amplifier (high line only)
2 AM/FM aerial and amplifier
3 Power amplifier (high line only)
4 Radio cassette player
5 Remote radio control switches
(mid line and high line only)
6 Upper front door speaker LH/RH
(high line only)
7 A post speaker LH/RH
(mid line and high line only)
8 Upper rear door speaker, LH/RH
(high line only)
9 Lower front door speaker LH/RH
10 CD-autochanger (if fitted)
11 Lower rear door speaker LH/RH
12 Radio headphone amplifier LH/RH
(high line only)
13 Tail door speakers (high line only)
