Discovery II
TORQUE WRENCH SETTINGS
06-5
Emission control - Td5
Emission control - V8
TORQUE DESCRIPTION
METRIC
IMPERIAL
EGR valve pipe Allen screws
10 Nm
(7 lbf.ft)
EGR valve to inlet manifold bolts
10 Nm
(7 lbf.ft)
EGR intake pipe clip to cylinder head bolts - if fitted
25 Nm
(18 lbf.ft)
EGR cooler to cylinder head nut and bolts - if fitted
25 Nm
(18 lbf.ft)
EGR valve to flexible mounting nuts
5 Nm
(3 lbf.ft)
EGR valve flexible mounting to bracket nuts
5 Nm
(3 lbf.ft)
TORQUE DESCRIPTION
METRIC
IMPERIAL
HO
2
S Sensors
45 Nm
(33 lbf.ft)
SAI air manifold union nuts
25 Nm
(18 lbf.ft)
Rubber mountings to SAI pump bracket
10 Nm
(7 lbf.ft)
SAI control valve to manifold bolts
10 Nm
(7 lbf.ft)
SAI pump to bracket nuts
10 Nm
(7 lbf.ft)
SAI pump bracket to body bolt
20 Nm
(15 lbf.ft)
Vacuum reservoir to mounting bracket bolt
10 Nm
(7 lbf.ft)
