Discovery II
TORQUE WRENCH SETTINGS
06-6
Engine management system - Td5
Engine management system - V8
+ Apply sealant, Part No. STC 50552 to threads
TORQUE DESCRIPTION
METRIC
IMPERIAL
ECT sensor
15 Nm
(11 lbf.ft)
Fuel tank cradle
45 Nm
(33 lbf.ft)
CKP sensor
10 Nm
(7 lbf.ft)
MAP and IAT sensor
10 Nm
(7 lbf.ft)
Fuel cooler to inlet manifold - upper bolts
25 Nm
(18 lbf.ft)
Turbocharger to exhaust manifold
30 Nm
(22 lbf.ft)
Turbocharger drain pipe
10 Nm
(7 lbf.ft)
Banjo bolt to oil feed pipe
25 Nm
(18 lbf.ft)
Fuel temperature sensor
14 Nm
(10 lbf.ft)
Pressure regulator
25 Nm
(18 lbf.ft)
Glow plugs
16 Nm
(12 lbf.ft)
EUI clamp bolts
32 Nm
(24 lbf.ft)
EGR valve to exhaust manifold
10 Nm
(7 lbf.ft)
EGR valve to inlet manifold
10 Nm
(7 lbf.ft)
EGR clip
25 Nm
(18 lbf.ft)
TORQUE DESCRIPTION
METRIC
IMPERIAL
Spark plugs
20 Nm
(15 lbf.ft)
Fuel tank cradle
45 Nm
(33 lbf.ft)
ECT sensor +
10 Nm
(7 lbf.ft)
CKP sensor
6 Nm
(4.4 lbf.ft)
CMP sensor
8 Nm
(6 lbf.ft)
KS sensor
22 Nm
(16 lbf.ft)
Throttle body
10 Nm
(7 lbf.ft)
Plenum chamber
22 Nm
(16 lbf.ft)
Breather adaptor
6 Nm
(4.4 lbf.ft)
Throttle cable abutment bracket
10 Nm
(7 lbf.ft)
TP sensor
2.2 Nm
(1.6 lbf.ft)
IACV sensor
8 Nm
(6 lbf.ft)
HO
2
S sensor
45 Nm
(33 lbf.ft)
Ignition coils
8 Nm
(6 lbf.ft)
Fuel rail
9 Nm
(7 lbf.ft)
