Discovery II
TORQUE WRENCH SETTINGS
06-19
Body
TORQUE DESCRIPTION
METRIC
IMPERIAL
Front and rear door hinges
30 Nm
(22 lbf.ft)
Tail door hinge bolts
34 Nm
(25 lbf.ft)
Door frames
10 Nm
(7 lbf.ft)
Regulator to glass
6 Nm
(4.4 lbf.ft)
Chassis cross member
25 Nm
(18 lbf.ft)
Bulkhead to chassis bolts
45 Nm
(33 lbf.ft)
Body to chassis bolts
45 Nm
(33 lbf.ft)
Quarter light glass to frame
10 Nm
(7 lbf.ft)
Glass lift motor to regulator
5 Nm
(3.7 lbf.ft)
Tail door hand rail
10 Nm
(7 lbf.ft)
Latch and motor assembly
7 Nm
(5.2 lbf.ft)
Door handle
7 Nm
(5.2 lbf.ft)
Damper to step
17 Nm
(13 lbf.ft)
Throttle pedal assembly
13 Nm
(10 lbf.ft)
Step assembly to chassis
45 Nm
(33 lbf.ft)
Wing to sill finisher bracket
17 Nm
(13 lbf.ft)
Front wing to body
17 Nm
(13 lbf.ft)
Door mirror
4 Nm
(3 lbf.ft)
Roof bars
32 Nm
(24 lbf.ft)
Bonnet release lever
10 Nm
(7 lbf.ft)
Front bumper to crash cans
13 Nm
(10 lbf.ft)
Front bumper to side mountings
13 Nm
(10 lbf.ft)
Mudshield
10 Nm
(7 lbf.ft)
Rear bumper
45 Nm
(33 lbf.ft)
Grab handle to body
3 Nm
(2.2 lbf.ft)
Fascia
26 Nm
(19 lbf.ft)
Fascia to steering column bracket
11 Nm
(8 lbf.ft)
Front seat to floor
45 Nm
(33 lbf.ft)
Second row seats to floor
45 Nm
(33 lbf.ft)
Third row seats to lower rear quarter
22 Nm
(16 lbf.ft)
Sunroof tray to frame
2 Nm
(1.5 lbf.ft)
Solenoid securing cap
11 Nm
(8 lbf.ft)
Support stay to alternator
25 Nm
(18 lbf.ft)
Sunroof glass
3 Nm
(2.2 lbf.ft)
Motor to sunroof tray
2 Nm
(1.5 lbf.ft)
Drive cable assembly to frame
2.5 Nm
(1.8 lbf.ft)
Front and rear door striker bolts
26 Nm
(19 lbf.ft)
Tail door striker bolts
26 Nm
(19 lbf.ft)
