Discovery II
TORQUE WRENCH SETTINGS
06-11
Transfer box - LT230SE
† New nut must be fitted
* New Patchlok nut must be fitted
+ Apply sealant, Part No. STC 50552 to threads
TORQUE DESCRIPTION
METRIC
IMPERIAL
High/low selector cable
30 Nm
(22 lbf.ft)
Bottom cover plate bolts +
25 Nm
(18 lbf.ft)
Transfer box to gearbox bolts - Petrol and diesel +
45 Nm
(33 lbf.ft)
Rear cover plate stud nut/bolts +
25 Nm
(18 lbf.ft)
Differential lock warning lamp switch locknut - Up to 03 MY
11 Nm
(8 lbf.ft)
Differential lock warning lamp switches - 03 MY onwards +
25 Nm
(18 lbf.ft)
Drive flange nut
148 Nm
(109 lbf.ft)
Output shaft housing bolts +
45 Nm
(33 lbf.ft)
Oil temperature sensor - If fitted +
25 Nm
(18 lbf.ft)
Inhibitor switch to transfer box
26 Nm
(19 lbf.ft)
Intermediate shaft nut †
88 Nm
(65 lbf.ft)
Intermediate shaft retaining plate bolt +
25 Nm
(18 lbf.ft)
Differential bearing retaining nut *
72 Nm
(53 lbf.ft)
Output flange nut
162 Nm
(119 lbf.ft)
High/Low selector housing bolts +
25 Nm
(18 lbf.ft)
Bearing housing/cover bolts +
25 Nm
(18 lbf.ft)
Blanking plug +
25 Nm
(18 lbf.ft)
High/Low selector warning lamp switch
25 Nm
(18 lbf.ft)
Differential lock selector housing bolts +
25 Nm
(18 lbf.ft)
Neutral sensor
25 Nm
(18 lbf.ft)
Interlock solenoid bolts - Up to 03 Model Year
10 Nm
(7 lbf.ft)
