Discovery II
TORQUE WRENCH SETTINGS
06-10
Manual gearbox - R380
+ Apply sealant, Part No. STC 50552 to threads
TORQUE DESCRIPTION
METRIC
IMPERIAL
Bias spring adjustment plate bolts +
25 Nm
(18 lbf.ft)
Gearbox to engine bolts
45 Nm
(33 lbf.ft)
Coolant pipe housing bolts
25 Nm
(18 lbf.ft)
Breather pipe banjo bolt
15 Nm
(11 lbf.ft)
Gear lever extension clamp bolt
25 Nm
(18 lbf.ft)
Gearbox mounting bolts
85 Nm
(63 lbf.ft)
Gearbox mounting nuts
48 Nm
(37 lbf.ft)
Seal housing bolts
18 Nm
(13 lbf.ft)
Bearing sleeve bolts
25 Nm
(18 lbf.ft)
Fork bolt
7 Nm
(5.2 lbf.ft)
Reverse light switch
24 Nm
(18 lbf.ft)
Extension housing bolts +
25 Nm
(18 lbf.ft)
Gear selector housing bolts +
25 Nm
(18 lbf.ft)
Oil pump to housing Torx screws
6 Nm
(4.4 lbf.ft)
Gear change lever yoke Allen screw +
25 Nm
(18 lbf.ft)
5th gear stake nut
350 Nm
(258 lbf.ft)
Spool retainer bolts
8 Nm
(6 lbf.ft)
Centre plate detent spring and ball Torx screw
25 Nm
(18 lbf.ft)
Selector lever to housing bolts +
25 Nm
(18 lbf.ft)
Clutch \ Bell housing bolts
73 Nm
(54 lbf.ft)
