Discovery II
TORQUE WRENCH SETTINGS
06-12
Automatic gearbox - ZF4HP22
+ Apply sealant, Part No. STC 50553 to threads
TORQUE DESCRIPTION
METRIC
IMPERIAL
Selector lever to selector shaft nut
26 Nm
(19 lbf.ft)
Starter inhibitor switch bolts
10 Nm
(7 lbf.ft)
Engine to torque converter bolts - Td5 & V8 +
50 Nm
(37 lbf.ft)
Closing plate to gearbox housing bolt - V8
7 Nm
(5.2 lbf.ft)
Fluid pump to intermediate plate bolts
10 Nm
(7 lbf.ft)
Intermediate plate Allen plugs (M14)
40 Nm
(30 lbf.ft)
Intermediate plate Allen plugs (M20)
50 Nm
(37 lbf.ft)
Oil cooler adaptors
42 Nm
(31 lbf.ft)
Extension housing bolts
25 Nm
(18 lbf.ft)
Oil sump to gearbox housing bolts
8 Nm
(6 lbf.ft)
Oil filter Torx screws
8 Nm
(6 lbf.ft)
Oil pick-up tube Torx screw
8 Nm
(6 lbf.ft)
Parking pawl guide Torx screw
10 Nm
(7 lbf.ft)
Pressure regulator to valve body assembly
8 Nm
(6 lbf.ft)
Lock-up solenoid valve, retaining fork Torx screw
8 Nm
(6 lbf.ft)
Lock-up solenoid valve assembly to valve body Torx screws
8 Nm
(6 lbf.ft)
Gearbox bell housing (intermediate plate and converter housing to gearbox casing) bolts
46 Nm
(34 lbf.ft)
Speed sensor bracket screws
8 Nm
(6 lbf.ft)
