Discovery II
TORQUE WRENCH SETTINGS
06-20
Heating and air conditioning
Wipers and washers
TORQUE DESCRIPTION
METRIC
IMPERIAL
Heater assembly
16 Nm
(12 lbf.ft)
Compressor bolts
22 Nm
(16 lbf.ft)
Blower motor
19 Nm
(14 lbf.ft)
Compressor to mounting bracket bolts
25 Nm
(18 lbf.ft)
A/C pipes to compressor bolts
10 Nm
(7 lbf.ft)
Condenser pipe bolt
5 Nm
(3.7 lbf.ft)
Receiver drier to bracket bolts
5 Nm
(3.7 lbf.ft)
Adaptor block to receiver drier bolt
5 Nm
(3.7 lbf.ft)
Evaporator pipe bolts
5 Nm
(3.7 lbf.ft)
Dual pressure switch to receiver drier
10 Nm
(7 lbf.ft)
Air conditioning pipes to receiver drier bolts
5 Nm
(3.7 lbf.ft)
TX valve pressure pipe union
22 Nm
(16 lbf.ft)
Evaporator pipe to TXV valve
32 Nm
(24 lbf.ft)
Evaporator assembly to body bolts
16 Nm
(12 lbf.ft)
High and low pressure pipe, bolts
10 Nm
(7 lbf.ft)
Fuel burning heater Torx bolts
25 Nm
(18 lbf.ft)
TORQUE DESCRIPTION
METRIC
IMPERIAL
Link to motor spindle
7 Nm
(5.2 lbf.ft)
Front motor assembly
2.5 Nm
(1.8 lbf.ft)
Spindle nut
3 Nm
(2.2 lbf.ft)
Wiper arm nut
13 Nm
(10 lbf.ft)
