Discovery II
TORQUE WRENCH SETTINGS
06-21
Electrical
TORQUE DESCRIPTION
METRIC
IMPERIAL
Alternator support stay
25 Nm
(18 lbf.ft)
Alternator lead - Td5
6 Nm
(4.4 lbf.ft)
Auxiliary drive belt tensioner bolt
50 Nm
(37 lbf.ft)
Alternator pulley
80 Nm
(59 lbf.ft)
Alternator B+ nut - V8
18 Nm
(13 lbf.ft)
Alternator B+ nut - V8
5 Nm
(3.7 lbf.ft)
Starter motor - Td5
27 Nm
(20 lbf.ft)
Starter motor solenoid
10 Nm
(7 lbf.ft)
Starter motor - V8
44 Nm
(32 lbf.ft)
Alternator
45 Nm
(33 lbf.ft)
Starter motor heat shield - V8
10 Nm
(7 lbf.ft)
Horn
13 Nm
(10 lbf.ft)
Battery carrier bolts
28 Nm
(21 lbf.ft)
