Discovery II
TRANSFER BOX - LT230SE
REPAIRS
41-37
5. Remove seal from transfer box.
Refit
1. Clean seal mating faces.
2. Fit new seal using tool LRT-41-012.
CAUTION: Oil seal must be fitted dry.
3. Position drive flange, fit new felt and steel
washers.
4. Position tool LRT-51-003 and tighten new
drive flange nut to 148 Nm (109 lbf.ft).
5. Fit propeller shaft.
6. Top-up transfer box oil.
