Freelander Service Procedures
SECURITY
REPAIRS
86-4-7
Refit
1. Fit volumetric sensor and secure with screws.
2. Connect multiplug to sensor.
3. Raise headlining and secure with trim studs.
4. Up to 04MY: Position front interior lamp and
connect multiplug.
5. Up to 04MY: Fit Torx bolts securing interior
lamp and tighten to 6 Nm (4.4 lbf.ft).
6. Up to 04MY: Fit lens to front interior lamp.
7. From 04MY: Position front interior lamp and
connect multiplug.
8. From 04MY: Fit and secure front interior lamp
to headlining.
9. Position 'B/C' post upper finisher and secure
with clips.
10. Fit sun visor.
11. Fit grab handles, tighten screws and fit screw
covers.
12. Fit 'A' post upper finisher.
REPAIRS, Trim finisher - 'A' post - upper -
renew.
13. Fit rear quarter upper trim casing.
REPAIRS, Trim casing - rear quarter - upper
- 5 door.
14. Secure front and rear door seals.
Module (ECU) - volumetric - alarm
system - 5 door - with sunroof
$% 86.77.29
Remove
1. Release front and rear door aperture seals.
2. Remove 'A' post upper finishers.
REPAIRS, Trim finisher - 'A' post - upper -
renew.
3. Remove screw covers, remove 6 screws
securing front and both rear grab handles and
remove grab handles.
4. Remove grab handle blanking plugs.
