L322 Range Rover Service Procedures
DOORS
76-1-16 REPAIRS
Finisher - upper - tailgate lower
$% 76.34.44
Remove
1. Open upper and lower tailgates.
2. Remove 6 screw caps.
3. Remove 6 screws securing trim finisher.
4. Remove trim finisher.
Refit
1. Fit trim finisher and secure with screws.
2. Fit screw covers.
Latch - front door
$% 76.37.12
This procedure is also applicable to the rear door
latch.
Remove
1. Ensure window is fully raised.
2. Remove plastic sheet.
DOORS, REPAIRS, Plastic sheet -
DOORS, REPAIRS, Plastic sheet -
3. Release sill button lock rod from door latch.
4. Remove rod.
5. Disconnect multiplug from latch.
6. Disconnect door handle release cable from
latch assembly.
7. Remove 3 Torx screws securing latch to door.
8. On drivers door, release door lock barrel
paddle from latch.
9. Remove latch from aperture.
M76 4487
