L322 Range Rover Service Procedures
DOORS
76-1-18 REPAIRS
Refit
1. Position support bracket to latch, fit bolts and
tighten to 10 Nm (7 lbf.ft).
2. Connect manual release cable.
3. Position latch assembly to tailgate and connect
multiplug.
4. Fit bolts to latch and tighten to 10 Nm (7 lbf.ft).
5. Fit tailgate trim casing.
6. Adjust tailgate striker.
Latch - outer - tailgate
$% 76.37.83
Remove
1. Open upper and lower tailgates.
2. Remove 2 Torx screws and latch.
Refit
1. Align latch assembly, ensure drive is engaged.
Fit Torx screws and tighten to 25 Nm (18 lbf.ft).
