L322 Range Rover Service Procedures
ENGINE - V8
12-2-78 OVERHAUL
Pulley - crankshaft
$% 12.21.01.01
Disassembly
1. Loosen 2 bolts securing ancillary drive belt
tensioner and release tension from the belt.
2. Remove ancillary drive belt.
3. Loosen 2 bolts securing A/C compressor drive
belt tensioner and release tension from the belt.
4. Remove compressor drive belt.
5. Remove 8 bolts securing crankshaft pulley to
hub assembly.
6. Remove crankshaft pulley.
7.
Reassembly
1. Clean crankshaft pulley and mating face.
2. Position crankshaft pulley to hub assembly, fit
to locating dowel.
3. Fit 8 new bolts securing crankshaft pulley to
hub assembly and tighten to 22 Nm (16 lbf.ft).
4. Clean A/C compressor drive belt pulleys.
5. Fit A/C compressor drive belt, rotate tensioner
fully clockwise and tighten the tensioner bolts to
22 Nm (16 lbf.ft).
6. Clean ancillary drive belt pulleys.
7. Fit ancillary drive belt, rotate tensioner fully
clockwise and tighten tensioner bolts to 22 Nm
(16 lbf.ft).
