LT230Q Transfer Box
TRANSFER BOX
30
OVERHAUL
61. Using a round nosed punch, stake collar of nut
into recess in differential shaft.
Main casing
1. Fit a new differential rear bearing track using
tool LRT-51-009.
2. Using a straight edge and feeler gauges, check
that bearing track is recessed 1.0 mm (0.04 in)
below outer face of main casing.
3. Using a suitable mandrel, fit a new mainshaft
input gear bearing track.
CAUTION: Ensure bearing tracks are
seated squarely in recesses.
