Range Rover P38
SUPPLEMENTARY RESTRAINT SYSTEM
9
REPAIR
AIRBAG MODULE - DRIVER SIDE
Service repair no - 76.73.71
Remove
1. Disconnect both battery terminals, negative lead
first.
2. Disconnect Supplementary Restraint System
(SRS) ’shorting link’.
3. Unscrew 4 bolts (TX 30 Torx bit) securing
module to steering wheel.
NOTE: Fixings remain captive in steering
wheel.
NOTE: Rotate steering wheel for access to
all fixings.
4. Release module from steering wheel, disconnect
multiplug.
5. Remove module.
CAUTION: Store the airbag module
correctly.
See Description and operation.
Refit
NOTE: If a new airbag module is being
fitted, the serial numbers must be
recorded.
6. Position module and connect multiplug.
7. Tighten bolts to
9 Nm. (7 lbf.ft)
8. Connect SRS ’shorting link’ and secure
connector to location.
9. Connect battery terminals, positive before
negative. Fit and secure battery cover.
10. Check SRS using TestBook .
