Range Rover P38
PANEL REPAIRS
11
SEALING AND CORROSION PROTECTION
MATERIALS GUIDE
3M Automotive Structural Adhesive 08120
a two-part epoxy structural adhesive, with ’automix’
twin-cartridge dispenser. For door skin and for
bonding panel stiffeners. Supplied as twin pack for
use in small trigger gun (No. 08190).
3M Bolted Panel Sealer 08572
Preformed strip 20 mm (0.8 in) wide x 2 mm (0.08 in)
thick supplied in 4.6 metre (81.2 in) reels.
Permanently flexible with good adhesion, for sealing
wing to body joints and other bolted or riveted panels.
3M Body Caulking 08568
Thumb-applied sealing compound supplied in
60-packs of preformed strips 300mm (11.8in) long x
6mm (0.24in) wide. For sealing large openings and
fissures. Non-hardening, does not dry out or crack,
can be overpainted immediately.
3M Drip-Chek Sealer Heavy 08531
For use on vertical fissures and seams up to 3mm
(0.12in.) wide for a firm but flexible seal which will not
harden or shrink. Self-levelling, will not sag on vertical
surfaces. May be worked with a tool or smoothed with
a wet finger.
Supplied in 150 ml (4.5 fl oz) tubes.
3M Drip-Chek Sealer Clear 08401
An easily flowing sealer similar to Drip-Chek Heavy
but of clear consistency. Ideal for an almost invisible
spot weal over finished paintwork. Can be overpainted
or even mixed with paint colour to form a self-coloured
sealant.
Supplied in 150 ml (4.5 fl oz) tubes.
3M Super Seam Sealer 08537
A brushable sealer designed to simulate original
factory-applied sealer on all overlap joints such as
floor pans, wheel arches, boot and load space seams
and fuel filler cap surrounds. Resistant to oil, petrol
and water. Should be brushed on in ONE direction
only for best results.
WARNING: Must be stored under
conditions applicable to highly flammable
materials.
3M Flexseal 08684, 08689 AND 08694
A high solid, non-shrinking, polyurethane body sealer
for use in either a hand gun or pneumatic applicator
gun. Excellent adhesion and sealing properties.
Resistant to oil, petrol and water. Supplied in 310 ml
(9 fl oz) cartridges and in a choice of black, white or
grey.
3M Polyurethane Sachet Sealer 08703, 08783,
08788
Similar to Flexseal polyurethane but available in
collapsible foil sachets in 310 ml (9 fl oz) and 600 ml
(18 fl oz) sizes with a choice of three colours: black,
grey or white.
3M Windscreen Sealer 08509
Non-hardening sealant for dry-glazed,
weatherstrip-type windscreens. Applied with applicator
gun.
Supplied in 310 ml (9 fl oz) cartridges.
3M Spray Schutz 08877, Body Schutz 08861
Flexible, rubberised, fast-drying coating which dries to
a black textured finish.
Spray Schutz supplied in 600 ml (18 fl oz) aerosols.
Spray Schutz and Body Schutz also supplied in 1-litre
(1.76 pt) cartridges to fit Schutz Gun.
