R380
1
REPAIR
R380 GEARBOX
Service repair no - 37.20.02
Remove
1. Site vehicle on ramp and chock wheels.
2. Disconnect battery negative lead.
3. Remove fan blade assembly.
NOTE: The nut securing viscous unit has
left hand thread.
4. Disconnect airflow meter to plenum chamber
hose. (V8i only)
5. Remove two gear lever knobs.
6. Remove floor mounted console assembly.
See
CHASSIS AND BODY, Repair, Centre
Console
7. Remove padding from top of transmission
tunnel.
8. Loosen pinch bolt and remove upper gear lever.
9. Remove screws and detach high low lever and
main gear lever retaining plates.
Underneath vehicle
10. Drain oil from transfer gearbox, main gearbox
and extension housing.
11. Refit plugs.
12. Disconnect heated oxygen sensor and remove
front section of exhausts. (V8i only)
13. Remove chassis cross member secured by eight
nuts and bolts. (V8i only)
