Front Door Exterior Handle: Service and Repair

Removal and Installation

1. Remove the front door trim panel.
2. Position the watershield aside.

3. Remove the screws and the anti-theft guard.

4. Remove the exterior door handle screw.

5. Disconnect the exterior door handle actuating rod.

1. Release the clip.
2. Disconnect the actuating rod.
