E 320 Coupe (124.052) L6-3.2L (104.992) (1994)
-
Push in cables for airbag squib (38a) and horn (32k) through the recesses in the steering wheel (see arrows) and the grommet in the impact
absorber.
-
Insert slip ring and install with new screws (32j). Tightening torque 6 Nm.
-
Disconnect cable (38d) from flat-pin plug (38e) and connect to the flat-pin plug of the slip ring.
-
Connect cable which has been pushed in for horn (32k) in the upper right contact plate (arrow).
