Sable V6-3.0L DOHC VIN S (2002)
9. Using the special tools remove the RH differential seal metal protector.
1. Rotate the Front Cover Seal Remover.
2. Rotate the forcing screw while holding the front cover seal remover.
3. Remove the metal protector of the seal.
10. Using the special tools remove the rubber portion of the seal.
1. Rotate the Front Cover Seal Remover.
2. Rotate the forcing screw while holding the front cover seal remover.
3. Remove the rubber portion of the seal.
Installation
1. Using the special tools install the left hand differential seal.
2. Using the special tools install the right hand seal.
3. Install the halfshafts into the vehicle.
